Striebel & John U51 Recessed small distribution board 5-row IP31, 834 x 310 x 120 mm, 60TE, 1-field
2CPX030104R9999
- Type U51 Sub-distribution Board
- 400V AC 50/60 Hz
- 834 x 310 x 120 mm
€164.90 VAT incl.
The Type U51 Sub-distribution Board with the item number 2CPX030104R9999 originates from Germany and belongs to the U series. It is a partially built cabinet for indoor use. The sub-distribution board is protection-insulated (protection class II) but can be upgraded to protection class I with an earthing set.
The device is equipped with a rated operating voltage Ue of 400V AC 50/60 Hz and a rated current In of 125 A. The level of protection is IP31, but IP30 when the door is removed. The cabinet is powder coated in RAL 9016, with a steel door and standard lock. Moreover, the door opening angle can be up to 120 degrees and can swing to either the right or left.
The installation is recessed, with the cable entry from the top through a supplied nipple flange and from the bottom through a pre-stamped flange opening. The device dimensions are 834 x 310 x 120 mm for height, width, and depth respectively.
Note that technical changes to the products and changes in the content of this document can be made at any time without prior notice.
